What's new

Fader Tray

A new dedicated fader interface provides quick access to audio level controls for your entire immersive project. The Fader Tray organizes faders into three pages—Sources, Spaces, and Groups—allowing you to manage levels across different elements of your system from a single location. Each fader includes gain and mute controls with real-time metering, and the interface supports a sends-on-fader mode for routing individual sources to specific spaces. Switch between pages using the vertical tabs on the left side of the tray, and access the Fader Tray from the bottom panel of the project window.

Spaces can now be controlled with overall gain and mute settings, giving you master level control for each acoustic space in your room simulation. These controls are available both in the fader tray's Spaces page and in the Space properties panel, and they integrate seamlessly with automation and cue editing workflows.

Measuring Tool

Measure distances directly in the 3D viewport with the new Measuring Tool. Use CTRL + M on Windows or CMD + M on MacOS to activate the tool. Click two points anywhere in your project to see the distance displayed in real-time, with automatic calculation of time delay based on your project's speed of sound settings. Measurements are displayed in your preferred units and can be cleared by pressing ESC. The Measuring Tool works in both Design and Mapping viewports, making it easy to verify dimensions and calculate delays throughout your project.
